PCX® System: Removable Davit System for Concrete Parapets
250 lb. capacity – material handling only
3 lift length options – 50′, 80′, 120′.
The OZ PCX® System is a removable, non-penetrating parapet clamp davit system designed specifically for rooftop material handling on solid concrete parapet walls.
Engineered as a complete specified system, the PCX® Clamp secures to the top of a solid concrete parapet wall without drilling or permanent installation, creating a reliable anchor point for the PCX® 250 davit crane, for lifting operations up to 250 lb.
Unlike permanent rooftop lifting solutions, the PCX® System provides a fully removable lifting solution that can be redeployed across multiple rooftop locations without structural modification. With minimal tools required for installation, the PCX® System can be set up quickly, removed just as easily, and reused across multiple locations—saving time while increasing jobsite flexibility.
The PCX® Clamp is a reusable, two-piece davit base, engineered to fit over the top of a solid concrete parapet wall, without drilling or permanent installation. During installation, the clamp halves are positioned around the parapet and secured by tightening the main threaded rod, which applies clamping force to the wall, creating a stable temporary anchor point for material handling lifts.
Paired with the OZ PCX® 250 davit crane and manual brake winch, the davit installs into the PCX® Clamp in seconds with OZ’s tool-free Quick Connect System.
This complete kit delivers smooth, controlled lifting with a 250 lb capacity. Built from durable steel with an exterior-grade powder coat, designed for real-world conditions, it’s a dependable solution for rooftop material handling where safety, efficiency, and portability matter.
System includes:
Applications:
Ideal for rooftop maintenance and material handling applications where permanent lifting equipment is impractical or undesirable, including:
Common applications include commercial buildings, hospitals, universities, hotels, data centers, government and municipal facilities, airports, telecommunications facilities, infrastructure, bridges, and marine/port facilities.
NOTE: Engineered for use exclusively as part of the PCX® System. Use only with approved PCX® components. Site and structural suitability must be verified by a qualified engineer prior to installation. Material handling only. Not for lifting personnel.
Tell us about your needs and we will match you with the ideal lifitng solution
| Model | ALL POSITIONS |
|---|---|
| OZPCXS-50 | 250 lb [113 kg] |
| OZPCXS-80 | 250 lb [113 kg] |
| OZPCXS-120 | 250 lb [113 kg] |
| *Based on 3/16 inch galvanized wire rope |
| Model | Mast Moment (in-lb) | Mast Moment (N-m) |
|---|---|---|
| OZPCXS-50 | 15,507 | 1,752 |
| OZPCXS-80 | 15,507 | 1,752 |
| OZPCXS-120 | 15,507 | 1,752 |
| *Moment measured from mast centerline. |
