OZIND050-20CH Downloads

Industrial Chain Hoist

OZIND050-20CH

Industrial Chain Hoist

5 T Industrial Chain Hoist 20 ft lift

Custom rigging available. Standards – CE, ASME B30.16 and AS1418.2

The Industrial Chain Hoist designed for a 5 T capacity delivers robust performance with its all-steel construction and grade 80 zinc-plated load chain. It includes fully enclosed gearing for smooth operation with minimal lifting effort. The Weston-style brake system with a twin pawl design ensures both safety and efficiency. Finished with a long-lasting powder coat and provided with a free spare set of latches, this hoist is built to perform reliably in heavy-duty industrial applications.

  • All-steel construction for maximum durability
  • Grade 80 zinc-plated load chain
  • Forged alloy steel hooks
  • Weston-Style brake system with twin pawl design
  • Fully enclosed gearing
  • Minimal load lifting effort
  • Load sheave bearings
  • Thrust bearing on lower hook
  • Heavy-duty latches
  • Zinc-plated hand chain
  • Long-lasting powder coat finish
  • Free spare set of latches included for convenience

OZIND050-20CH

5 T Industrial Chain Hoist 20 ft lift

    Videos

    Photos

    Add-Ons

    System Components

    Specs & Ratings

    Capacity - Ton (kg) 5 (4536)
    Effort to Lift S.W.L - lb (kg) 88 (40)
    Falls of Chain
    Load Chain Diameter – in (mm) 0.39x1.18 (10x30)
    Dimensional Information - in (mm) A 26.8 (680.72)
    B 10.2 (259.08)
    C 7.4 (187.96)
    Hook-opening, Upper & Lower – in (mm) D 2.6 (66.04)
    Net Weight of Head Only – lb (kg) 56.2 (25.55)

    IMPORTANT!

    *Dimensions, weights, and illustrations are for reference only and subject to change without notice.
